Key Performance Factors
Modern MTB Design
Tapered fork steerer tubes, quality components like a 1x drivetrain* with a clutch-equipped rear derailleur, thru-axle hubs, internal cable routing (including dropper post compatibility), and integrated chainstay protection provide everything you need to build confidence and skills on the trails. (select models)
Off-Road Control
The new geometry is optimized for confident trail riding, with two wheel size options (27.5- or 29-inch) based on frame size. It's also designed to match front suspension travel with either an 80mm or 100mm fork. All models have clearance for high-volume tires (up to 2.4 inches) for traction and grip on technical terrain.
Light and Durable
The all-new ALUXX aluminum frame features updated tube shaping and a lighter overall weight for improved performance on off-road terrain.
Specifications
Specifications
| Grips | Giant Sole-O |
| Handlebar | Giant Connect Trail, 31.8mm |
| Pedals | MTB caged |
| Saddle | Liv ErgoContact Trail |
| Seatpost | Giant Sport, 30.9mm |
| Stem | Giant Sport, 7-degree XS: 40mm (27.5) S: 40mm (27.5) / 40mm (29) M: 50mm (29) |
| Bottom Bracket | Cartridge |
| Brake Levers | Tektro TKD143 |
| Brakes | Tektro TKD149, hydraulic |
| Brakes Rotor | Tektro rotors [F]180mm, [R]160mm |
| Cassette | MicroShift H093, 11x46 |
| Chain | KMC X9 |
| Crankset | ProWheel Charm, 32t (27.5) or 30t (29) XS: 165mm (27.5) S: 165mm (27.5) / 170mm (29) M: 170mm (29) |
| Front Derailleur | N/A |
| Rear Derailleur | microSHIFT Advent, M6195M w/clutch |
| Shifters | microSHIFT Advent, 1x9 |
| Fork | SXC32-3 RL, coil spring, Boost 15x110 XS: 80mm travel (27.5) S: 80mm travel (27.5) / 100mm travel (29) M: 100mm travel (29) |
| Frame | ALUXX-Grade aluminium, disc |
| Hubs | Alloy, sealed |
| Rims | Giant GX03V 29 or 27.5, alloy, double wall |
| Spokes | Stainless, 14g |
| Tyres | Maxxis Rekon 27.5x2.4" Maxxis Rekon Race 29x2.4", wire bead |
